F17 Structural Formply 17mm | High Strength Concrete Formwork Plywood 1800×1200mm
High Strength and Stability: Designed for heavy-duty applications with consistent load-bearing capacity.
Smooth Surface Finish: Provides a uniform concrete finish and reduces surface defects.
Waterproof Glue (WBP): Ensures resistance to moisture, extending product lifespan.
Versatility: Suitable for formwork in various construction projects.
Certified Quality: Meets F17 stress grade requirements and AS 6669 standards for reliability.
F17 Structural Formply 17mm
F17 Structural Formply is a high-performance plywood panel specifically designed for concrete formwork and structural construction applications. Manufactured from selected hardwood veneers and bonded with waterproof phenolic resin, it provides excellent load-bearing capacity, dimensional stability, and repeated use performance.
The 1800×1200×17mm panel is widely used in commercial buildings, infrastructure projects, bridges, and residential construction throughout Australia, New Zealand, and other international markets.
Key Features
- Certified F17 structural rating
- High bending strength and load capacity
- Waterproof phenolic resin bonding
- Smooth surface for superior concrete finish
- Excellent dimensional stability
- Reusable for multiple construction cycles
- Suitable for wall, slab, beam and column formwork
- Complies with Australian construction requirements
| Specification | Details |
|---|---|
| Product Name | F17 Structural Formply |
| Thickness | 17mm |
| Size | 1800 × 1200mm,1200*2400mm |
| Face/Back | Phenolic Film Faced |
| Core | Hardwood Core |
| Glue | Phenolic WBP Glue |
| Structural Rating | F17 |
| Density | 620-720 kg/m³ |
| Moisture Content | 8%-14% |
| Edge Sealing | Waterproof Painted Edges |
| Application | Concrete Formwork & Structural Construction |
Applications
F17 Structural Formply is suitable for:
- Concrete wall formwork
- Slab formwork systems
- Column formwork
- Bridge construction
- Infrastructure projects
- Commercial building construction
- Residential housing projects
- Industrial concrete casting
Why Choose LUJU Structural Formply
- More than 15 years of plywood manufacturing experience
- Strict quality control from veneer selection to final inspection
- Stable supply capacity for large construction projects
- OEM and customized specifications available
- Competitive factory-direct pricing
- Exported to Australia, New Zealand, Middle East and Southeast Asia
FAQ
What is F17 Structural Formply?
F17 Structural Formply is a high-strength plywood panel rated for structural formwork applications and designed to withstand heavy concrete loads.
How many times can F17 Formply be reused?
Under proper handling and maintenance, F17 formply can be reused multiple times depending on project conditions.
Is F17 Formply waterproof?
Yes. It is manufactured with waterproof phenolic resin adhesive and sealed edges for enhanced moisture resistance.
What sizes are available?
Standard sizes include 1800×1200mm and customized dimensions upon request.
