H20 Beam for Formwork and Concrete Construction

H20 Beam for Formwork

The H20 Beam is an essential component of modern formwork systems, providing dependable support for concrete structures in residential, commercial, and infrastructure projects. Manufactured from carefully selected timber and reinforced for enhanced durability, our H20 beams deliver outstanding load-bearing performance and dimensional stability.

Designed to withstand demanding construction environments, these beams offer a long service life and multiple reuses, helping contractors reduce overall project costs. Their lightweight design also allows for easier handling and faster assembly on-site.

As a professional formwork beam manufacturer in China, LUJU Leader Wood supplies high-quality H20 beams to customers worldwide, supporting projects ranging from small buildings to large-scale civil engineering works.

Key Features

Excellent Load Capacity

Built with high-quality timber and engineered construction, H20 beams provide strong support for concrete formwork applications.

Lightweight and Easy to Handle

Compared with steel alternatives, timber beams are easier to transport, install, and dismantle.

Long Reuse Life

Protective coating and strict manufacturing standards help extend the service life of each beam.

Stable Performance

Carefully controlled moisture content reduces warping, twisting, and cracking during use.

Custom Lengths Available

Various beam lengths can be produced according to project requirements.

Technical Specifications

Parameter	Specification
Product  Name	H20 Timber Beam for Formwork
Brand	Leader
Beam Height	200mm
Flange Width	80 mm
Flange Height	40mm
Length	2.45/2.65/2.9/3.3/3.9/4.5/4.9/5.9m; Customized
Web thickness	27mm/30mm
The Material of Flange:	Graded timber or Structural laminated lumber
The Material of Web	plywood/3 layers-Plywood
Flange wood species	softwood
Service Class	3(exterior conditions)
Adhesive	Type I per EN301
Moisture Content	12+-2% at time of dispatching
Weight	Approx 5.0kg/m
Standard packaging	50/100/105pcs per package

Applications

Our H20 formwork beams are widely used in:

• Slab formwork systems
• Wall formwork systems
• Column formwork
• Bridge construction
• Tunnel engineering
• Infrastructure projects
• Commercial building construction

Why Choose LUJU Leader Wood

• Professional wood products manufacturer
• Strict quality control system
• Customized specifications
• Competitive factory-direct pricing
• Fast international delivery
• Export experience to Europe, Middle East, Asia and South America

FAQ

What are H20 beams used for?

H20 beams are primarily used as structural support members in concrete formwork systems.

Why choose timber formwork beams?

Timber beams offer an excellent balance of strength, lightweight handling, and cost efficiency.

Can beam lengths be customized?

Yes. We manufacture H20 beams in customized lengths according to customer requirements.

Are your beams suitable for large construction projects?
