Formwork H20 Timber Beams – Strong, Reusable Construction Wood
Formwork H20 Timber Beams – Strong, Reusable Construction Wood
OurFormwork H20 Timber Beams are designed to meet the demanding requirements of modern construction. Crafted from high-quality kiln-dried timber, these beams provide excellent load-bearing capacityandlong-lasting stability in concrete formwork applications.
Ideal for slabs, walls, columns, bridges, and tunnels, these beams combine lightweight handlingwithrobust structural support, making them a cost-effective solution for contractors seeking reusable and reliable formwork components.
LUJU Leader Wood manufactures these beams in custom lengths and dimensions, ensuring a perfect fit for every construction project. With global export experience, we deliver H20 beams that meet international standards and provide consistent performance on site.
Key Features
- High Load-Bearing Capacity – Safe support for concrete formwork.
- Reusable Timber Beams – Long service life reduces project costs.
- Lightweight & Easy to Install – Simplifies handling and assembly.
- Custom Sizes Available – Beams tailored to project specifications.
- Kiln-Dried and Stable Timber – Minimizes warping, cracks, and moisture issues.
Technical Specifications
| Parameter | Specification |
|---|---|
| Product Name | H20 Timber Beam for Formwork |
| Brand | Leader |
| Beam Height | 200mm |
| Flange Width | 80 mm |
| Flange Height | 40mm |
| Length | 2.45/2.65/2.9/3.3/3.9/4.5/4.9/5.9m; Customized |
| Web thickness | 27mm/30mm |
| The Material of Flange: | Graded timber or Structural laminated lumber |
| The Material of Web | plywood/3 layers-Plywood |
| Flange wood species | softwood |
| Service Class | 3(exterior conditions) |
| Adhesive | Type I per EN301 |
| Moisture Content | 12+-2% at time of dispatching |
| Weight | Approx 5.0kg/m |
| Standard packaging | 50/100/105pcs per package |
Applications
- Concrete slab, wall, and column formwork
- Bridge and tunnel construction support
- Temporary scaffolding and construction structures
- Residential and commercial building projects
Why Choose LUJU Leader Wood
- Professional H20 timber beam manufacturer
- Strict quality control for durable and reusable beams
- Customizable lengths and dimensions for all projects
- Competitive factory-direct pricing for international buyers
- Export-ready packaging and reliable worldwide shipping
FAQ
Q1: Are Formwork H20 Timber Beams suitable for large-scale projects?
A1: Yes, they are widely used in bridges, tunnels, and large commercial or civil engineering projects.
Q2: How do you ensure beam consistency?
A2: All beams undergo strict quality control, kiln-drying, and coating to guarantee stability and performance.
Q3: Can the beams be reused?
A3: Yes, with proper handling, these timber beams can be reused multiple times.
Q4: What sizes do you offer?
A4: Standard beams are 80×200 mm, with customizable lengths to meet project requirements.
Q5: Do you ship internationally?
A5: Yes, we export worldwide, including Europe, Middle East, Asia, and South America.Request Your Free Quote Today
