H20 Shuttering Beam – Reliable Timber for Concrete Formwork

Premium H20 Beam for Formwork and Shuttering

OurH20 shuttering beams are engineered to provide stable and reliable support in a variety of concrete formwork systems. Manufactured from high-quality timber, these beams are carefully kiln-dried to ensure minimal warping, cracking, or twisting, even under demanding construction conditions.

Ideal for residential, commercial, and large infrastructure projects, H20 beams combine lightweight handling with high load-bearing capacity, reducing labor costs and improving on-site efficiency.

LUJU Leader Wood offers customizable lengths and specifications, ensuring each beam fits your project requirements perfectly. With long-lasting durability and international export experience, our H20 beams are trusted by contractors worldwide.

Key Features

• High Strength & Load Capacity – Supports heavy concrete structures safely.
• Lightweight & Easy to Handle – Faster installation and labor savings.
• Multiple Reuse Cycles – Durable timber designed for repeated formwork use.
• Customizable Lengths – Beams cut to your exact project specifications.
• Kiln-Dried Timber – Minimizes deformation, cracks, and moisture-related issues.

Technical Specifications

Parameter	Specification
Product  Name	H20 Timber Beam for Formwork
Brand	Leader
Beam Height	200mm
Flange Width	80 mm
Flange Height	40mm
Length	2.45/2.65/2.9/3.3/3.9/4.5/4.9/5.9m; Customized
Web thickness	27mm/30mm
The Material of Flange:	Graded timber or Structural laminated lumber
The Material of Web	plywood/3 layers-Plywood
Flange wood species	softwood
Service Class	3(exterior conditions)
Adhesive	Type I per EN301
Moisture Content	12+-2% at time of dispatching
Weight	Approx 5.0kg/m
Standard packaging	50/100/105pcs per package





Applications

• Concrete slab formwork
• Wall and column formwork
• Tunnel and bridge construction
• Temporary supports in civil engineering
• Commercial and residential construction projects

Why Choose LUJU Leader Wood

• Professional H20 beam manufacturer with international experience
• Customizable beam lengths and specifications
• Kiln-dried timber for long-lasting durability
• Reliable factory-direct pricing and worldwide shipping
• High-quality beams trusted by contractors globally

FAQ

Q1: What makes H20 shuttering beams different from regular timber beams?
A1: H20 shuttering beams are engineered specifically for concrete formwork, providing higher load capacity and stability under heavy loads.

Q2: How do you ensure beam durability?
A2: All beams are kiln-dried, coated, and strictly quality-controlled to minimize warping, cracking, and moisture damage.

Q3: Can H20 beams be reused?
A3: Yes, high-quality H20 beams can be reused multiple times depending on project handling.

Q4: What sizes are available?
A4: Standard sizes are 80×200 mm, with customizable lengths available for all project requirements.

Q5: Do you export internationally?
A5: Yes, we export H20 beams worldwide, including Europe, the Middle East, Southeast Asia, and South America.Get a Free Quote Now
